Long distance, M30 cylinder Simplified type, CMD

CN-T100MR

  • Long distance: 100m
    • Secure detection in harsh environment, with high power
  • Provided with three-point received light intensity indicator
    • Helpful for adjustment of optical axis
  • Embedded with AC/DC power circuit
    • Either 48-240VAC or 24-240VDC can be used as power supply
    • Covering AC/DC (NPN/PNP) control, with photo MOS (1a)
Contact us about this series

Downloads

Manual

CN-T100MR

Model Detecting distance Operating mode Output mode Response time Power supply Protective structure
CN-T100MR 100m Dark ON Photo MOS output 10ms or less 48 - 240V AC IP67
Contact

More Info

CN-T100MR

Transmitter

Receiver
