Quick Change AC/DC SENSORS
J Series
- Quick replacement feature
- 3 openings for cables
- Metal and mirror-like objects are detected
- Flat body integrating many functions
- Offers much larger wiring space
Photoelectric Sensor
J Series
J Series
| Model | Detection method | Detecting distance | Output mode | Operation mode | Protective structure | |
|---|---|---|---|---|---|---|
| JRM3R | Polarized retroreflective | 0.03 - 3m | Relay output 1a | Light ON/Dark ON | IP66 | |
| JRM3RF | Polarized retroreflective | 0.03 - 3m | Relay output 1a | Light ON/Dark ON + Timer function | IP66 | |
| JR07 | Diffuse reflective | 700mm | Relay output 1a | Light ON/Dark ON | IP66 | |
| JR07F | Diffuse reflective | 700mm | Relay output 1a | Light ON/Dark ON + Timer function | IP66 | |
| JT10R | Through beam | 10m | Relay output 1a | Light ON/Dark ON | IP66 | |
| JT10RF | Through beam | 10m | Relay output 1a | Light ON/Dark ON + Timer function | IP66 |
Accessories
K-7
60 x 40mm Reflector for Polarized Retroreflective models
More Info
- Metal and mirror-like objects are detected
- Flat body integrating many functions
- Offers much larger wiring space
Mounting bracket (accessory) attached
- JIS B 0202 PF1/2 screws used
- Compatible cable diameter: 9-11 mm
- When using cable diameters of 6-8 mm, use optional bushings (JV7).
Relay output type
