Fiber Optic Sensors F2R Series
Takex F2R Fiber Optic Photoelectric Sensor
Slim Type

F2R Series

  • Amazingly slim size
    (8 x 10 x 73 mm)
  • Low cost
    • NPN and PNP output types are available
    • High speed response of 500μs
  • Set models with fiber optic cables are also available.
    • Reflective type with fiber optic cables: F2R-FR8E
    • Through beam type with fiber optic cables: F2R-FT8E
    • The fiber optic cable features 50 cm free cutting. (M3 P = 0.5 head)
Contact us about this series

F2R Series

Model Light source (wavelength) Output mode Response time Connection Protective structure
F2R Red LED (660nm) NPN open collector 500 μs or less Attached cable IP65
Contact
F2R-J Red LED (660nm) NPN open collector 500 μs or less Connector type
(cable with connector separately available)		 IP65
Contact
F2RPN Red LED (660nm) PNP open collector 500 μs or less Attached cable IP65
Contact
F2RPN-J Red LED (660nm) PNP open collector 500 μs or less Connector type
(cable with connector separately available)		 IP65
Contact

More Info

F2R, F2RPN (attached cable)

F2R-J, F2RPN-J (connector type)

With DIN rail mounting bracket attached(F2R, F2RPN)

With DIN rail mounting bracket attached(F2R-J, F2RPN-J)

Pitch for adjacent screw mounting (14 mm)

In the condition of load short circuit or overload, the output transistor turns off. Check the load condition before restarting.

Connector type (-J) pin assignment
